Rack Quick Disconnect Module Double-Shutoff Valve Leakage Standards – Official Technical Overview & Hardware Datasheet

EXECUTIVE SUMMARY

The Rack Quick Disconnect Module Double-Shutoff Valve Leakage Standards (RQDM-DSV) establishes a new benchmark for fluid containment integrity in carrier-grade telecom rack environments. Engineered for mission-critical liquid-cooled and dielectric-fluid systems, this module integrates dual redundant shutoff valves with precision leakage control, ensuring zero-downtime operation and environmental compliance. This datasheet outlines the hardware architecture, performance specifications, and compliance framework for OEM integration.

ARCHITECTURE & CHASSIS DESIGN

The RQDM-DSV is housed in a compact 1RU chassis constructed from marine-grade aluminum with corrosion-resistant coating. The double-shutoff valve assembly features two independent, spring-loaded poppet valves arranged in series, providing fail-safe isolation upon disconnection. The module includes integrated leak sensors, pressure transducers, and a local status LED array. Quick-disconnect couplings are rated for 10,000 mating cycles and are compatible with standard 3/8-inch and 1/2-inch fluid lines.

HARDWARE FEATURES

– Dual redundant shutoff valves with automatic closure on disconnection
– Leakage rate: Parameter Specification

Form Factor 1RU Chassis (19-inch rack mount) Valve Configuration Double-shutoff, series redundant Leakage Rate Operating Pressure 0.5 to 10 bar Fluid Compatibility Water, glycol, dielectric fluids Coupling Type Quick-disconnect, 3/8 or 1/2 inch Mating Cycles 10,000 minimum Power Supply 1+1 Redundant AC/DC Operating Temperature -20°C to +60°C (standard); -40°C to +70°C (extended) Ingress Protection IP54 Compliance IEC 60529, ISO 16016, UL 94 V-0, Telcordia GR-63-CORE, NEBS Level 3

ORDERING OPTIONS

– RQDM-DSV-01: Standard 1RU module, 3/8-inch couplings, AC power
– RQDM-DSV-02: 1RU module with 1/2-inch couplings, DC power
– RQDM-DSV-03: Redundant power input version
– RQDM-DSV-04: Extended temperature range (-40°C to +70°C)
