Huawei CE6880-48T4Q2CQ-EI Switch with 48-Port 10G RJ45, 6-Port 40GE QSFP+ or 44-Port 10G RJ45, 4-Port 40GE QSFP+, 2-Port 100GE QSFP28, Without Fan and Power Module

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

CE6880-48T4Q2CQ-EI overview



The CloudEngine 6800 series switches deliver high performance, high port density, and low latency, making them ideal for building cloud-oriented data center networks for enterprises and carriers. Featuring a cutting-edge hardware design, the series offers access ports with 10 GE, 25 GE, or 50 GE options, along with uplink ports supporting 40 GE, 100 GE, or 200 GE. With advanced data center capabilities, high-performance stacking technologies, and flexible airflow designs, the series ensures superior efficiency and scalability.

The CloudEngine 6800 is ideal for both core and aggregation layers and seamlessly integrates with CloudEngine 16800 and 12800 series switches. This compatibility allows enterprises to create scalable, streamlined, open, and secure networks.

Item Details
Description

02350SRD Switch (48-Port 10G RJ45, 6-Port 40GE QSFP+ or 44-Port 10G RJ45, 4-Port 40GE QSFP+, 2-Port 100GE QSFP28, Without Fan and Power Module)
Part Number 02350SRD
Model CE6880-48T4Q2CQ-EI

CE6880-48T4Q2CQ-EI Appearance

48T

1 Power supply slot 1

Applicable power modules:

  • 600 W AC Power Module (PAC-600WA)
  • 600 W DC Power Module (PDC600S12)
 2 Power supply slot 2

Applicable power modules:

  • 600 W AC Power Module (PAC-600WA)
  • 600 W DC Power Module (PDC600S12)
3 Fan slot 1

Applicable fan modules:

  • FAN-40HA series fan modules
 4 Fan slot 2

Applicable fan modules:

  • FAN-40HA series fan modules
5 Console port 6 ETH management port (RJ45)
7

Barcode label

NOTE:

This label is drawable, and you can pull it outward to view the ESN barcode and MAC address of the switch.

 8 USB port
9 Forty-eight 10GBASE-T Ethernet electrical ports 10 Two 40GE/100GE QSFP28 Ethernet optical ports

NOTE:

  • A QSFP28 Ethernet optical port can be split into four 10GE ports.
  • The default rate of a QSFP28 Ethernet optical port is 40 Gbit/s, and you can use the port mode 100ge command to change the port speed to 100 Gbit/s.
  • After the speed of 40GE1/0/1 is changed to 100 Gbit/s, ports 10GE1/0/45 and 10GE1/0/46 transition to Down (port unavailable) state. After the speed of 40GE1/0/2 is changed to 100 Gbit/s, ports 10GE1/0/47 and 10GE1/0/48 become unavailable.

Applicable modules and cables:

  • 40GE optical module
  • 100GE optical module (QSFP28-100G-4WDM-40 not supported)
  • QSFP+ to QSFP+ AOC cable
  • QSFP+ to 4*SFP+ AOC cable
  • QSFP+ to 4*SFP+ high-speed cable
  • QSFP+ to QSFP+ high-speed cable (When a QSFP+ to QSFP+ high-speed cable is installed on the port, the cable can only be used as a stack cable. In V200R005C10 and later versions, the cable can also be used to connect peer-link interfaces in an M-LAG)
  • QSFP28 to QSFP28 AOC cable
  • QSFP28 to QSFP28 high-speed cable
11 Four 40GE QSFP+ Ethernet optical ports

NOTE:

A 40GE QSFP+ port cannot be split into four 10GE ports.

Applicable modules and cables:

  • 40GE optical module
  • QSFP+ AOC cable (QSFP+ to QSFP+)
  • QSFP+ to QSFP+ high-speed cable (When a QSFP+ to QSFP+ high-speed cable is installed on the port, the cable can only be used as a stack cable. In V200R005C10 and later versions, the cable can also be used to connect peer-link interfaces in an M-LAG)
 12 Three port-side mounting holes for mounting brackets
13 Four power-supply-side mounting holes for mounting brackets 14 Ground screw

Item

CE6880-48T4Q2CQ-EI
Physical specifications
  • Dimensions (W x D x H): 442.0 mm x 420.0 mm x 43.6 mm (17.4 in. x 16.5 in. x 1.72 in.)
  • Weight (with two power modules and two fan modules, calculated based on the heaviest model if multiple models are supported): 9.0 kg (19.84 lb)
Environment parameters Temperature
  • Operating temperature: 0°C to 40°C (32°F to 104°F) at altitude of 0-1800 m (0-5906 ft.)
    NOTE:
    When the altitude is 1800-5000 m (5096-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
  • Storage temperature: -40°C to +70°C (-40°F to +158°F)
Relative humidity 5% RH to 95% RH, noncondensing
Altitude < 5000 m (16404 ft.)
Noise (sound pressure, 27°C)
  • Back-to-front airflow: < 53 dBA
  • Front-to-back airflow: < 53 dBA
Power specifications Power source type AC
AC power input
  • Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz
  • Maximum input voltage range: 90 V AC to 290 V AC, 47 Hz to 63 Hz
DC power input
  • Rated voltage range: -48 V DC to -60 V DC
  • Maximum voltage range: -38.4 V DC to -72 V DC
High-voltage DC power input Not supported
Rated input current
  • 600 W AC power (PAC-600WA series): 9 A (100 V AC to 240 V AC)
  • 600 W DC power (PDC600S12 series): 20A (-48 V DC to -60 V DC)
Chassis power consumption Maximum power consumption 430 W
Typical power consumption 266 W (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules)
Chassis heat dissipation Maximum heat dissipation 1466 BTU/hr
Typical heat dissipation 906 BTU/hr (100% throughput, 3 m Ethernet cables on 48 ports and QSFP+ cables on 6 ports, double power modules)
Surge protection
Power module:
  • AC: 6 kV in common mode and 6 kV in differential mode
Heat dissipation Heat dissipation mode Air cooling
Airflow Front-to-back or back-to-front, depending on the fan modules and power modules
Reliability Power module backup 1+1 backup
Fan module backup 1+1 backup not supported
NOTE:
A CE6800 chassis uses two fan modules, with each fan module containing two fans. The four fans in the chassis work in 3+1 backup mode.
Hot swap Supported by all power modules and fan modules
Mean time between failures (MTBF) 49.13 years
Mean time to repair (MTTR) 1.83 hours
Availability 0.99999575382
Technical specifications Processor 1.5 GHz, eight-core
DRAM Memory 2 GB
NOR Flash 32 MB
NAND Flash 1 GB
Stack Service port supporting the stack function 10GE electrical ports, 40GE optical ports, and 100GE optical ports
Certification
  • Safety standards compliance
  • EMC standards compliance
  • Environmental standards compliance
