Huawei CE8800 switch CE8850-SAN with 32*100GE QSFP28

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

CE8850-SAN Overview

Item Details
Description CE8850-SAN switch (32*100GE QSFP28,without fan and power modules)
Part Number 02354FPQ
Model CE8850-SAN
First supported version V300R020C10SPC200
Other part numbers 02354FPS (CE8850-SAN switch (32*100GE QSFP28, 2*AC power modules, 6*fan modules, port-side intake))

02354FPT (CE8850-SAN switch (32*100GE QSFP28, 2*AC power modules, 6*fan modules, port-side exhaust))
Short Name CE8850-SAN

CE8850-SAN Appearance

CE8850 SAN



1. Ground screw 2. USB port 3. Console port 4. ETH management port (RJ45) 5. Six Fan slots
6. Two Power supply slots 7. Thirty-two 100GE SFP28/Thirty-two 200GE SFP56 Ethernet optical ports 8. Eight 400GE QSFP-DD Ethernet optical ports 9.Equipment serial number (ESN) and MAC address

NOTE:

You can scan the code to view the ESN and MAC address of the switch.

 10. Three port-side mounting holes for mounting brackets
11. Equipotential bonding

Ground screws for a ground cable with a two-hole OT terminal

 12. Four power-supply-side mounting holes for mounting brackets – – –
Item CE8850-SAN
Switching capacity To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel.
CPU 4-core, 1.4 GHz
Memory DRAM: 8 GB
NOR Flash 64 MB
NAND Flash 4 GB
USB It can be used for log backup and USB-based deployment. This function is reserved.
Power supply mode
  • AC pluggable
  • DC pluggable
  • HVDC pluggable
Console port RJ45
Downlink Service interface 32 x 100GE QSFP28/32 x 200GE QSFP56
Uplink Service interface 8 x 400GE QSFP-DD
Service port supporting the stack function Reserved function. This function is not enabled.
RTC Supported
Typical power consumption [W]
  • 32x200G+8x400G: 590 W (50% traffic load, copper cables on all ports, normal temperature, dual power modules)
  • 32x100G+8x400G: 560 W (50% traffic load, copper cables on all ports, normal temperature, dual power modules); 693 W (50% traffic load, short-distance optical modules on all ports, normal temperature, dual power modules)
Typical heat dissipation [BTU/hour]
  • 32 x 200G + 8 x 400G: 2013 BTU/hour (50% traffic load, copper cables on all ports, normal temperature, dual power modules)
  • 32 x 100G + 8 x 400G: 1912 BTU/hour (50% traffic load, copper cables on all ports, normal temperature, dual power modules), 2363 BTU/hour (50% traffic load, short-distance optical modules on all ports, normal temperature, dual power modules)
Static power consumption [W] 455 W
Static heat dissipation [BTU/hour] 1757 BTU/hour
Maximum power consumption [W]
  • 32 x 200G + 8 x 400G: 1152 W (100% traffic load, 6.5 W 200G optical modules on all downlink ports, 12 W 400G optical modules on all uplink ports, high temperature of 40°C, dual power modules)
  • 32 x 100G + 8 x 400G: 973 W (100% traffic load, 5 W 100G optical modules on all downlink ports, 12 W 400G optical modules on all uplink ports, high temperature of 40°C, dual power modules)
Maximum heat dissipation [BTU/hour]
  • 32 x 200G + 8 x 400G: 3927 BTU/hour (100% traffic load, 6.5 W 200G optical modules on all downlink ports, 12 W 400G optical modules on all uplink ports, high temperature of 40°C, dual power modules)
  • 32 x 100G + 8 x 400G: 3323 BTU/hour (100% traffic load, 5 W 100G optical modules on all downlink ports, 12 W 400G optical modules on all uplink ports, high temperature of 40°C, dual power modules)
Number of power modules 2
Redundant power supply 1+1 backup
Rated input voltage [V]
  • 1200 W AC or 240 V DC power module: 100 V AC to 240 V AC, 50/60 Hz; 240 V DC
  • 1200 W DC power module: –48 V DC: –48 V DC to –60 V DC; +48 V DC: +48 V DC
Input voltage range [V]
  • 1200 W AC&240 V DC power module: AC: 90 V AC to 290 V AC, 45 Hz to 65 Hz; DC: 190 V DC to 290 V DC
  • 1200 W DC power module: -48 V DC: -38.4 V DC to -72 V DC; +48 V DC: +38.4 V DC to +60 V DC
Maximum input current [A] 1200 W AC&240 V DC power modules:
  • 10 A (100 V AC to 130 V AC)
  • 8 A (200 V AC to 240 V AC)
  • 8 A (240 V DC)
1200 W DC power module: 38 A
Rated output power [W]
  • 1200 W AC&240 V DC power module: 1200 W
  • 1200 W DC power module: 1200 W
Certification
  • Compliance with safety standards
  • Compliance with EMC standards
  • Compliance with environment and environmental protection standards
Power supply surge protection [kV] AC power protection: 6 kV in common mode and 6 kV in differential mode 240 V HVDC power protection: 4 kV in common mode and 2 kV in differential mode –48 V DC power supply protection: 4 kV in common mode and 2 kV in differential mode
Types of fans Pluggable
Number of fan modules 6
Redundant fans The device supports 5+1 backup of fan modules that work in hot standby mode. The system can operate normally for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately.
Heat dissipation mode Air cooling
Airflow direction Port-side air intake or port-side air exhaust, depending on the fan modules and power modules that are used. The fan modules and power modules must have the same airflow direction.
Availability 0.9999920679
MTBF [year] 21.59 years
Noise at normal temperature (27°C, sound pressure) [dB(A)]
  • Front-to-back airflow: 56.5 dB(A) on average (maximum: 61.7 dB(A))
  • Back-to-front airflow: 58.7 dB(A) on average (maximum: 62.9 dB(A))
Noise at high temperature (40°C, sound pressure) [dB(A)]
  • Front-to-back airflow: 71.8 dB(A) on average (maximum: 78.3 dB(A))
  • Back-to-front airflow: 74.5 dB(A) on average (maximum: 78.9 dB(A))
Long-term operating altitude [m (ft.)] ≤ 5000 m (16404 ft.)
Long-term operating relative humidity [RH] 5% RH to 95% RH, non-condensing
Long-term operating temperature [°C (°F)] 0°C to 40°C (32°F to 104°F) at an altitude of 0–1800 m (0–5906 ft.)
NOTE:
When the altitude is 1800–5000 m (5096–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage altitude [m (ft.)] ≤ 5000 m (16404 ft.)
Storage relative humidity [RH] 5% RH to 95% RH, non-condensing
Storage temperature [°C (°F)] -40ºC to +70ºC (-40°F to +158°F)
RTU License Supported Yes A 200GE interface works at the rate of 100 Gbit/s by default and can work at the rate of 200 Gbit/s only after an RTU license is activated. 400GE interfaces cannot be used by default and are available only after an RTU license is activated.
Dimensions with packaging (H x W x D) [mm (in.)] 260 mm x 790 mm x 590 mm (10.24 in. x 31.10 in. x 23.23 in.)
Dimensions without packaging (H x W x D) [mm (in.)]
  • Basic dimensions (the depth excludes the parts protruding from the body): 43.6 mm x 442 mm x 600 mm (1.72 in. x 17.40 in. x 23.62 in.)
  • Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442 mm x 625.5 mm (1.72 in. x 17.40 in. x 24.63 in.)
Weight without packaging [kg (lb)] 9.1 kg (excluding optical modules, power modules, and fan modules)
Weight without packaging (full configuration) [kg (lb)] 12.2 kg (including AC power modules and fan modules, excluding optical modules)
Weight with packaging [kg (lb)] 13.4 kg (29.54 lb)
Weight with packaging (full configuration) [kg (lb)] 16.5 kg (36.37 lb)
Chassis height [U] 1 U
Installation Type Cabinet Installation

Additional information

Brand

Huawei
Lead Time

3-5 days
Ship From

Shenzhen Warehouse
