HG6143D

HG6143D GPON Terminal with 4*GE+1*POTS+2*USB+2.4G/5G WIFI(5dBi)

Fiberhome

3-5 days

Shenzhen Warehouse

SKU: 2008141 Category:

Description

FiberHome ONT HG6143D Dual Band WiFi Optical Network Terminal

GPON: 4*GE+1*POTS+2USB+2.4G/5G WIFI

Antenna gain: 5dbi

Connector type: SC/UPC

TR069 Supported

ENG Firmware, ENG Indicators

Compatible with FiberHome OLT

Item HG6143D
Interface 4*GE+1*POT+2USB+2.4G/5G WIFI (5dBi)
Dimensions
(length x width x height)
36.8*204*149mm
Weight 90g
System power supply 12 V DC, 1.5 A
Power consumption ≤17W
Working environment Operating temperature: -5ºC to 45ºC
Storage temperature: -40ºC to 70ºC
Environment humidity: 10% to 95%, non-condensing

Additional information

Dimensions 3.68 × 20.4 × 14.9 cm

Fiberhome ONT comparation

Model HG6143D

AN5506-01-A

AN5506-02-FG

AN5506-04-F

HG6145D1

Format Routing type Bridge type Routing type Routing type Routing type
Ports 4*GE+1*POT+2*USB 1*GE 1*GE+1*FE+1*POTS 4*GE+2*POTS 4*GE+1*POTS+2*USB
WLAN 2.4/5G WIFI Non-WIFI 2.4G WIFI 2.4G WIFI 2.4/5G WIFI

Q: Can I use the commands to manage HG6143D through Fiberhome OLT?

A: Yes, HG6143D supports Fiberhome OLT OMCI protocol.



Q: Can I customize my company logo on the shell?

A: All ONT products of Telecomate.com support customized service, but the MOQ is 1000.



Q: Can I use the LAN port to power the monitor?

A: The LAN port of the ONT does not have the Power Over Ethernet function. If necessary, please select the ONU product.



Q: Is HG6143D compatible with the TP-LINK router?

A: Yes, there is no compatibility issue between ONT and the home routers.

4 reviews for HG6143D

  1. 5 out of 5

    José manuel

    Real a good model, full Gigabit Lan ports, 2.4/5.8G dual-band WIFI, high gain antennas, but with the best price. We will continually use this model in the future network deployment.

  2. 5 out of 5

    Javier

    Compatible with OMCI proprietary protocol with my OLT-Fiberhome AN5516-01, which is convenient for our management

  3. 5 out of 5

    Delia

    Buy two for testing, i will place an order in May.

  4. 5 out of 5

    Daniel

    Delivery time from their factory is fast
