S2LQ6L2A

ZTW ZXR10 8900E series switches S2LQ6L2A card provides eight 40-GE optical interfaces (two CFP interfaces and six QSFP interfaces) and the MPLS 40-GE wire-speed access.

ZTE

SKU: S2LQ6L2A Category:

Description

S2LQ6L2A overview

The S2LQ6L2A card provides eight 40-GE optical interfaces (two CFP interfaces and six QSFP interfaces). It is applicable to all the ZXR10 8900E series switches and provides the MPLS 40-GE wire-speed access.
The S2LQ6L2A card provides the following functions:

• Large switching capacity
It provides eight 40-GE optical interfaces (six QSFP interfaces and two CFP interfaces), and supports MPLS forwarding.

• Gigabit out-of-band communication
The MCS module communicates with the CPU of the card through this function, for example, downloading the CPU initialization information.

• EPLD online upgrade
The EPLD of the S2LQ6L2A card provides the online upgrade function by simulating the JTAG interface.

• JTAG test
The S2LQ6L2A card connects to main chips of line interface cards through a daisy chain to conduct the JTAG test.

• Intelligent detection
Temperature, voltage, and power consumption monitoring circuits are designed on the card to implement real-time monitoring through the IIC bus.

• IPMC management and control unit
The IPMC of each line interface card connects to the IPMC of the MCS module through a bus to establish an intelligent platform management system.

• Synchronous Ethernet & IEEE 1588v2
It supports Synchronous Ethernet and IEEE 1588v2 time synchronization.

• Power supply management
A power management chip can control the power-on sequence of devices. A power management chip can control the power-on sequence of devices.

Parameter Specification
Silk screen name S2LQ6L2A
Dimensions 374.61 mm × 395.4 mm × 40.3 mm
Power consumption Static power consumption: about 90 W Full-load power consumption: 120 W
CPU Capacity Dual-core CPU, CPU speed: 800 MHz
Memory Maximum capacity 1 GB



Attribute Specification
QSFP CFP
transmission distance OM3–100 m, OM4–150 m 10 km
Central wavelength 850 nm 1270 nm, 1290 nm, 1310 nm, 1330 nm
Minimum optical power for transmission -7.6 dBm -7 dBm
Maximum optical power for transmission 2.4 dBm 2.3 dBm
receiving sensitivity -5.4 dBm ≥ -11.5 dBm
Overload optical power ≤ 4.0 dBm ≤ 3.5 dBm
Fiber type Multi mode Single mode
