ZXDSL 9806H ASTGC 32-channel ADSL2/2+ over POTS Card

SKU: ASTGC Category:

Description

ASTGC Overview

ZXDSL 9806H ASTGC 32-channel ADSL2/2+ over POTS Card.

Provide 32channels of ADSL2/2+ user interface and POTS/ISDN interface, complete ADSL2/ADSL2+ service access and voice separation.

ZXDSL 9806H supports multiple standard splitters such as national standard and European standard, and supports two types of user access, over POTS and over ISDN.

Provides the function of converting ATM cells to IP packets.

ASTGC Front Panel

ASTGC

ASTGC Datasheet
Item ASTGC
Typical power consumption (W) 19.80
Interface PIN 32
Maximum transmission distance 6.5km

Interface rate

Uplink rate: Up to 1 Mbps

Downlink rate: up to 26 Mbps

Modulation technique

DMT

IP packet transmission delay

The maximum frame delay<10 ms, the minimum frame delay<1 ms


Occupied bandwidth

Downlink band: 138 kHz ~ 2.208 MHz

Uplink band: 30 kHz ~ 138 kHz



Standardization

 ITU-T G.992.3, G.992.5 and ANSI T1.413 standards
Hot Swappable Supported
Dimensions(mm)  20.5*274*231.2

Additional information

Weight 3.0000 kg
Dimensions 27.0000 × 23.0000 × 2.0000 cm
