F670L V9.0
$19.00
F670L V9.0 GPON Terminal with 4*GE+1*POTS+2*USB+2.4G/5G WIFI, 4*5dBi antennas, Huawei/ZTE OLT Compatible
ZTE
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Comparison
- FAQ
- Download
- Reviews (4)
Description
F670L V9.0 overview
The F670L is an AC1200 dual-band Gigabit Premium triple-play GPON ONT. It comes with 4*GE LAN ports, one phone port, and next-generation multi-stream Wi-Fi, operating simultaneously in 2.4GHz 2×2 over 802.11n and 5GHz 2×2 over 802.11ac. Based on customer requirements, the maximum 5dBi gain antennas can enhance the Wi-Fi coverage area and improve performance.
AC1200 Dual Band Gigabit GPON Gateway F670L V9.0
GPON ONT F670L V9.0 Optical Network Terminal
GPON ONT, 4*GE, 1*POTS, 2*USB, 2.4G/5G WiFi
4*5dBi antennas
Connector type SC/UPC
ENG firmware, ENG interface, ENG indicator
WiFi Standard: IEEE 802.11ac
Can be configured by OLT or Web or NMS
Huawei/ZTE OLT Compatible
| Item | F670L V9.0 |
| Interfaces | 1 SC/UPC connector for GPON
4 RJ-45 ports for GE interface 1 RJ-11 ports for VoIP |
| WiFi | Frequency: 2.4 GHz, 5GHz
|
| Antennas | 4* 5dBi External antennas |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% | |
| System power supply | 12 V DC, 1.5 A |
| Dimensions (length x width x height) |
245mm x 215mm x 40mm |
Dual Band ONT Comparation
| Model Name | EG8145V5 | EG8247W | F670L-V9.0 | HG6145D1 | G-140W-C |
| Brand | Huawei | Huawei | ZTE | Fiberhome | Nokia |
| UNI(User Network Interface) | 4*GE+1*POTS+2*USB+2.4G/5G WIFI | 4*GE+1*POTS+USB+2.4G/5G WIFI with 4 antennas | 4*GE+1*POTS+2*USB+2.4G/5G WIFI | 4*GE+1*POT+2*USB+2.4G/5G WIFI | 4*GE+1*POTS+2*USB+2.4G/5G WIFI |
| Operating temperature | 0ºC to 40ºC | 0ºC to 40ºC | 0ºC to 40ºC | -5ºC to 45ºC | 0ºC to 40ºC |
| Environment humidity | 5% to 95% (noncondensing) | 5% to 95% (noncondensing) | 5% to 95% (noncondensing) | 10% to 95% (noncondensing) | 5% to 95% (noncondensing) |
| System power supply | 11–14 V DC, 1.5 A | 12V, 1.5 A | 12 V DC, 1.5 A | 12 V DC, 1.5 A | 12 VDC,1.5 A |
| Antenna gain | 5dBi | 5dBi | 5dBi | 5dBi | 5dBi |
| Weight | About 0.5 kg | About 0.5 kg | About 0.5 kg | About 0.5 kg | About 1 kg |
Q: What is the difference between four antennas and two antennas?
A: Four antennas can effectively improve 40% the coverage and stability of WIFI.
Q: Is F670L V9.0 compatible with ZTE OLT?
A: It is a solution based on ZTE regardless of PCB, chipset, or firmware, so it is not only compatible with ZTE OLT but also compatible with Huawei, Fiberhome, and Nokia OLT.
Q: Can I use OMCI to manage the F670L V9.0 via my ZTE C620?
A: Yes, this model supports ZTE OMCI protocol.
Q: What is the difference between the v9.0 version and the old version?
A: F670L V9.0 is better than the old version of F670L in terms of chip performance, firmware stability, and WiFi performance.
Q: What is the default login address of the firmware WebUI? And the IP address of the PC?
A: IP for the firmware: 192.168.1.1; IP for the PC local: 192.168.1.2.
Q: Can I change the default admin password?
A: Yes, you can inform your assigned technical sales manager of your needs.
Rogelio –
Good-looking appearance, the test results of 4 antennas are significantly improved compared to the previous version.
Catalina –
I will plan to order 5000 units/batch after i testing.
Jakub –
The appearance and firmware of the V9 version have been upgraded a lot compared with the previous version
Víctor –
Oops! I thought that the new version of F670 V9.0 would be more unstable than the old version, and the test proved me wrong! Its representation is more stable and faster than the old version.
