S5732-H24UM2CC

0 Reviews Write a review
PN02353HUC
AvailabilityIn Stock
WarrantyUp to 36 months i
×
Warranty Policy
We provide a comprehensive warranty policy.
Refer to the table for more details.

Original price was: $0.00.Current price is: $0.00.

Huawei S5732-H24UM2CC supports 24 100M/1000M/2.5GE/5GE/10GE ports, 4 GE/10GE/25GE SFP+ ports, 2 40GE/100GE QSFP+ ports, POE++

Description

S5732-H24UM2CC Overview

Huawei S5732-H24UM2CC comes with 24 100M/1000M/2.5GE/5GE/10GE ports, 4 GE/10GE/25GE SFP+ ports, 2 40GE/100GE QSFP+ ports, POE++

The Huawei CloudEngine S5732-H series switches are the next-generation enhanced all-optical Ethernet switches developed by Huawei. The CloudEngine S5732-H builds on Huawei’s unified Versatile Routing Platform (VRP) and boasts various IDN features.

Telecomate.com provides a full range of Huawei switch series, if you have any demands, please contact: csd@telecomate.com

S5732-H24UM2CC Quick Spec

24 100M/1000M/2.5GE/5GE/10GE ports, 4 GE/10GE/25GE SFP+ ports, 2 40GE/100GE QSFP+ ports, POE++

Forwarding performance is 960 MPPS

Switching capacity is 2.4Tbps/24 Tbps



S5732-H24UM2CC appearance and structure

S5732- H24UM2CC appearance and structure

1 Twenty-four 100M/1000M/2.5GE/5GE/10GE BASE-T PoE++ ports (multi-GE ports) 9 One PNP button
2 Four 1GE/10GE/25GE SFP28 optical ports 10 Fan module slot 1
3 Two 40GE/100GE QSFP28 optical ports

QSFP-100G-CWDM4 QSFP-100G-ER4-Lite

QSFP28-100G-LR4 QSFP28-100G-PSM4

11 Fan module slot 2
4 Ground screw 12 Fan module slot 3
5 SSD card slot 13 Fan module slot 4
6 One ETH management port 14 Power module slot 1
7 One USB port 15 Power module slot 1
S5732-H24UM2CC Datasheet
Item S5732- H24UM2CC
Fixed ports 24 100M/1000M/2.5GE/5GE/10GE ports, 4 GE/10GE/25GE SFP+ ports, 2 40GE/100GE QSFP+ ports
Memory (RAM) 4 GB
Flash 2 GB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF) 38.05 years
Mean time to repair (MTTR) 2 hours
Availability > 0.99999
Power supply surge protection Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode; Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Rated voltage range AC input: 100 V AC to 130 V AC, 200 V AC to 240 V AC, 50/60 Hz; High-Voltage DC input: 240 V DC
Maximum voltage range AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz High-Voltage DC input: 190 V DC to 290 V DC
Maximum power consumption (100% throughput, full speed of fans) Not providing the PoE function: 285 W (without card) 100% PoE loads: 1933 W (PoE: 1440 W, without card)
Typical power consumption (30% of traffic load, tested according to ATIS standard) 161 W (without card)
Operating temperature -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature -40°C to +70°C (-40°F to +158°F)
Relative humidity 5% to 95% (non-condensing)
Dimensions (W x D x H) 442 mm x 420 mm x 43.6 mm
Weight (with packaging) 8 kg (17.64 lb)

Additional information

Weight 9.0000 kg
Dimensions 43.6000 × 44.2000 × 44.6000 cm
Campus Switch
Brand
Lead Time
Ship From
S5732-H24UM2CC Datasheet
Item S5732- H24UM2CC
Fixed ports 24 100M/1000M/2.5GE/5GE/10GE ports, 4 GE/10GE/25GE SFP+ ports, 2 40GE/100GE QSFP+ ports
Memory (RAM) 4 GB
Flash 2 GB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF) 38.05 years
Mean time to repair (MTTR) 2 hours
Availability > 0.99999
Power supply surge protection Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode; Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Rated voltage range AC input: 100 V AC to 130 V AC, 200 V AC to 240 V AC, 50/60 Hz; High-Voltage DC input: 240 V DC
Maximum voltage range AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz High-Voltage DC input: 190 V DC to 290 V DC
Maximum power consumption (100% throughput, full speed of fans) Not providing the PoE function: 285 W (without card) 100% PoE loads: 1933 W (PoE: 1440 W, without card)
Typical power consumption (30% of traffic load, tested according to ATIS standard) 161 W (without card)
Operating temperature -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature -40°C to +70°C (-40°F to +158°F)
Relative humidity 5% to 95% (non-condensing)
Dimensions (W x D x H) 442 mm x 420 mm x 43.6 mm
Weight (with packaging) 8 kg (17.64 lb)
