Description
| Optical interface parameters | ||
| Parameter | Value | |
| Nominal bit rate | 2488320 kbit/s | |
| Line code pattern | NRZ | |
| Application code | L-16.2Je | |
| Transmission distance (km) | 80 to 100 | |
| Type of fiber | Single-mode LC | |
| Operating wavelength range (nm) | 1530 to 1560 | |
| Launched optical power range (dBm) | -2 to +3 | |
| Dispersion tolerance (ps/nm) | 2000 | |
| Minimum extinction ratio (dB) | 8.2 | |
| Mechanical Specifications | ||
| Dimensions (mm) | 25.4 (W) x 220 (D) x 254.1 (H) | |
| Weight (kg) | 1.1 | |
