S5731S-H48T4XC-A

S5731S-H48T4XC-A

Huawei S5731S-H48T4XC-A switch supports 48 10/100/1000BASE-T ports, 4 10GE SFP+ ports

SKU: 02352YRF Category:

Description

S5731S-H48T4XC-A Overview

Huawei S5731S-H48T4XC-A switch supports 48 10/100/1000BASE-T ports, 4 10GE SFP+ ports

The S5731-H series switches are the next-generation intelligent gigabit fixed switches developed by Huawei. The CloudEngine S5731-H builds on Huawei’s unified Versatile Routing Platform (VRP) and boasts various IDN features. For example, the integrated wireless AC capabilities can manage up to 1,024 wireless APs; the free mobility feature ensures consistent user experience; the VXLAN functionality implements network virtualization, and built-in security probes support abnormal traffic detection, and threat analysis even in encrypted traffic, and network-wide threat deception.



S5731S-H48T4XC-A Quick Spec

48 10/100/1000BASE-T ports

4 10GE SFP+ ports

Forwarding Performance: 252/462 Mpps

Switching capacity: 758 Gbps/67.58 Gbps



S5731S-H48T4XC-A appearance and structure

S5731S-H48T4XC-A appearance and structure

1 Forty-eight 10/100/1000BASE-T ports

SFP-1000Base-T

7 Ground screw
2 Four 10GE SFP+ ports

OMXD30000 OSX010000 OSX040N01

8 Fan module slot 1
3 One console port 9 Fan module slot 2
4 One ETH management port 10 Power module slot 1
5 One USB port 11  Power module slot 2
6 One PNP button  12  Rear card slot
Item S5731S-H48T4XC-A
Memory (RAM) 4 GB
Flash 1 GB in total. To view the available flash memory size, run the display version command.
Meantime between failures (MTBF) 55.31 years
Fixed port 48 10/100/1000BASE-T (PoE+) ports, 4 10GE SFP+ ports
Power supply surge protection Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode; Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Stack ports 10GE SFP+ ports on the front panel, or ports on the rear card
Rated voltage range AC input: 100 V AC to 240 V AC, 50/60 Hz; High-Voltage DC input: 240 V DC; DC input: -48 V DC to -60 V DC
Maximum voltage range AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz; High-Voltage DC input: 190 V DC to 290 V DC; DC input: -38.4 V DC to -72 V DC
Maximum power consumption (100% throughput, full speed of fans) 124 W (without card)
Typical power consumption (30% of traffic load, tested according to ATIS standard) 101 W (without card)
Operating temperature -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature -40°C to +70°C (-40°F to +158°F)
Relative humidity 5% to 95% (non- condensing)
Service port surge protection Common mode: ±6 kV
Dimensions (H x W x D) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.); Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 43.6 mm x 442.0 mm x 448.0 mm (1.72 in. x 17.4 in. x 17.7 in.)
Weight (with packaging) 9.5 kg (20.94 lb)



Additional information

Weight 9.5000 kg
Dimensions 43.6000 × 44.2000 × 42.0000 cm
