TN11MCA8

PN 03030MDD
8-Channel Spectrum Analysis Board
Shenzhen Warehouse
lead time 3-5 days
- +
Overview

Huawei OSN6800 OSN8800 8-Channel Spectrum Analysis Board, Monitoring 40Gbps Singal

Optical Specifications
Item Value
Operating wavelength range(nm) 1529-1561
Detect accuracy for central wavelength(nm) ±0.1
Channel spacing(GHz) 50/100
Detect range for single channel optical power(dBm) -30 to -10
Detect accuracy for optical power(dB) ±1.5
OSNR detection accuracy A(The OSNR of 10 Gbit/s signals can be detected.)(dB) ±1.5 (OSNR: 13 to 19)
±2 (OSNR: 19 to 23)
OSNR detection accuracy Ba(The OSNR of 10, 40, and 100 Gbit/s signals can be detected.(dB) ±1.5 (OSNR detection range: 13-23)
Numbers of optical interface(pcs) 8
Mechanical Specifications
Dimensions(mm) 264.6(H) x 50.8(W) x 220(D)
Weight(kg) 1.9
