OSGXGSD01

Huawei XGS-PON&GPON OLT DOSGXGSD01 Transceiver, SFP+, 1577nm(TX1)/1490nm(TX2)/1270nm(RX1)/1310nm(RX2), 9.953G(TX1)/2.488G(TX2)/9.953G(RX1)/2.488G(RX2)/1.244G(RX3), 8dBm/6dBm, 11dBm/10dBm, -32dBm/-33.5dBm/-35dBm, SC/UPC Compatible with SC/PC, Single-mode Module, XGS-PON&GPON OLT D

SKU: 34061988 Category:

Description

Item OSGXGSD01
Type One-fiber bidirectional optical module, D
Operating Wavelength(nm)

GPON channel:
Tx: 1490
Rx: 1310

XGS-PON channel:
Tx: 1577
Rx: 1270

 Encapsulation Type SFP+
Port Rate(Gbit/s)

GPON channel:
Tx: 2.488
Rx: 1.244

XGS-PON channel:
Tx: 9.953
Rx: 9.953/2.488

Minimum Output Optical Power(dBm) GPON channel: 6

XGS-PON channel: 8

Maximum Output Optical Power(dBm) GPON channel: 10

XGS-PON channel: 11

Maximum Receiver Sensitivity(dBm) GPON channel: -35

XG-PON channel: -33.5

XGS-PON channel: -32

Optical Connector Type SC
Optical Fiber Type Single-mode
Extinction Ratio(dB) 8.2
Dimension(D x W x H mm) 80x20x15
