Huawei S5735-S48P4X switch with 48 10/100/1000BASE-T ports, 4 10GE SFP+ ports, PoE+, without power supply equipped


3-5 days

Shenzhen Warehouse

SKU: 10335 PN: 98010943 Category: Tags: , ,


S5735-S48P4X overview

S5735-S48P4X is the Huawei S5735-S switch with 48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports, PoE+. Huawei CloudEngine S5735-S is a series of standard gigabit access switches that provide 24–48 flexible all-GE downlink ports and four fixed 10 GE uplink ports. They are designed for enterprise campus network access and aggregation, as well as data center access. Built on next-generation, high-performance hardware and with the Huawei Versatile Routing Platform (VRP), CloudEngine S5735-S switches boast advanced features, such as enhanced Layer 3 functionality, simplified O&M, flexible Ethernet networking, and mature IPv6 capabilities.

Telecomate.com provides a full range of Huawei switch series, if you have any demands, please contact: [email protected]


S5735-S48P4X quick specs

48 10/100/1000BASE-T ports, 4 10 GE SFP+ ports,

Forwarding performance is 132 Mpps

Switching capacity is 176 Gbps/432 Gbps


S5735-S48P4X appearance and structure


1 Forty-eight 100/1000BASE-T ports 6 One PNP button
2 Four 10GE SFP+ ports

OMXD30000 OSX010000 OSX040N01 SFP-10G-ZR SFP-10G-USR

7 Ground screw
3 One console port 8 Power module slot 1
4 One ETH management port  9 Power module slot 2
5 One USB port
Item S5735-S48P4X
Fixed port 48 10/100/1000BASE-T ports
4 10GE SFP+ ports
Forwarding performance 132 Mpps
Switching capacity 176 Gbps/432 Gbp
Management port ETH management port Supported
Console port (RJ45) Supported
USB port USB 2.0
CPU Frequency 1000 MHz
Core 4
Storage Memory (RAM) 1 GB
Flash memory Hardware: 512MB, of which 306MB is available for users
Power supply system Power supply type 1000 W AC PoE
Power supply redundancy 1+1 NOTE: the backup power supply is optional.
Rated voltage range AC input (1000 W AC PoE): 100 V AC to 240 V AC, 50/60 Hz
Maximum voltage range AC input (1000 W AC PoE): 90 V AC to 290 V AC, 45 Hz to 65 Hz
High-voltage DC input (1000 W AC PoE): 190 V DC to 290 V DC
(meeting 240 V high-voltage DC certification)
Maximum input current 8 A
Maximum power consumption of the device 77 W (without PD) 1661 W (with PD, PD power consumption of 1600 W)
Power consumption in the case of 30% traffic load1 59 W
Power consumption in the case of 100% traffic load1 68 W
Reliability MTBF (year)2 54.88
MTTR (hour) 2.19
Availability > 0.99999
Physical specifications Dimensions (H x W x D) 43.6 mm x 442 mm x 420mm
Chassis height 1 U
Chassis weight (including packaging) 7.64 kg

Additional information

Weight 10.0000 kg
Dimensions 42.0000 × 44.2000 × 4.3600 cm
